Goncalo Costa on 17 Nov 2022

Commented: Walter Roberson on 18 Nov 2022

Open in MATLAB Online

I am trying to numerically solve the following set of equations

M_mag = 1 ; %just some constant simplified here as 1

om = 2*pi*new_freq ; %new_freq is an array of values

C1 = exp(-1i*L.*om./c); % L and c are constant

% phi = exp(1i*om*L/c);

nume = exp(1i.*om.*n*L/c)*4.*n./((1+n).^2); % terms depending on n

denom = 1 + exp(2*1i.*om.*n*L/c).*((n-1)./(n+1)).^2; % terms depending on n

syms n

S = vpasolve(M_mag./C1 == nume./denom , n , guess) %guess is a numerical approach done via another equation, in this case it is 1.7

Whenever I try to use this, I get the following text:

Error using mupadengine/feval_internal

More equations than variables is only supported for polynomial

systems.

Error in sym/vpasolve (line 172)

sol = eng.feval_internal('symobj::vpasolve',eqns,vars,X0);

I have seen similar things being explain in the following link, but I don't understand the explanation. Same for this explanation.

Why can I not solve the equation this way? Is it the exponentials terms?

Thank you very much for your help.

##### 1 Comment Show -1 older commentsHide -1 older comments

Show -1 older commentsHide -1 older comments

Star Strider on 17 Nov 2022

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/1854258-how-do-i-correctly-use-vpasolve#comment_2470213

I usually use solve, and then vpa the result. It is generally more reliable, especially with functions with multiple roots.

Too much of this code is ‘over the horizon’ and out of sight to provide a specific response.

Sign in to comment.

Sign in to answer this question.

### Answers (2)

Torsten on 17 Nov 2022

Edited: Torsten on 17 Nov 2022

You have 2 equations for 1 unknown. MATLAB's symbolic toolbox does not solve such systems.

Is n supposed to be real or complex ?

##### 6 Comments Show 4 older commentsHide 4 older comments

Show 4 older commentsHide 4 older comments

Goncalo Costa on 17 Nov 2022

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/1854258-how-do-i-correctly-use-vpasolve#comment_2470533

But don't I just have one equation, the one inside the vpasolve function? I separated into parts, but overall it is just one equation, one equality, no?

Or am I missing something (I probably am)? Thanks for your help.

Walter Roberson on 17 Nov 2022

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/1854258-how-do-i-correctly-use-vpasolve#comment_2470553

Open in MATLAB Online

Any one call to vpasolve() or solve() is a call to solve simultaneous equations.

syms x

vpasolve( [4*x+5==9, 3*x - 7 == 2] )

does not try to independently solve [4*x+5==0] and [3*x-7==2]: it tries to find a single combination of values of the variables that solves all of the equations at the same time. You would not expect vpasolve( [4*x+5*y==9, 3*x - 7*y == 2] ) to produce independent solutions for each of the equations, and the action of solve() and vpasolve() for multiple equations does not change just because the multiple equations only have a single variable between them.

Your comments say "new_freq is an array of values" so if you work through, M_mag./C1 == nume./denom is an array of equations. A single solve() call would try to find a single x that solves all of the equations at the same time. A single vpasolve() call will simply refuse to handle the situation (except for polynomials)

So you need to ask vpasolve() to solve each of the equations one-by-one . Which is what my arrayfun() Answer does.

Torsten on 17 Nov 2022

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/1854258-how-do-i-correctly-use-vpasolve#comment_2470738

@Walter Roberson

You'll only get an answer if n can be complex-valued (which I doubt the OP aims at).

Torsten on 17 Nov 2022

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/1854258-how-do-i-correctly-use-vpasolve#comment_2470743

Edited: Torsten on 17 Nov 2022

Open in MATLAB Online

@Goncalo Costa

Implicitly, you have the equations

real(M_mag./C1 - nume./denom) == 0

and

imag(M_mag./C1 - nume./denom) == 0

And you have a symbolic variable n.

Whether you get a solution that fits your needs depends on whether you accept a complex-valued n or not.

Goncalo Costa on 18 Nov 2022

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/1854258-how-do-i-correctly-use-vpasolve#comment_2471283

n is a complex number. Can I change my code for a complex result?

Thank you very much for your help.

Goncalo Costa on 18 Nov 2022

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/1854258-how-do-i-correctly-use-vpasolve#comment_2471293

@Walter Roberson that makes sense, I thought that it would solve one-by-one. I didn't understand the limitations of this tool. How can I go around this to have this equation solved for an array? Would a for loop be needed?

Sign in to comment.

Walter Roberson on 17 Nov 2022

Open in MATLAB Online

M_mag = 1 ; %just some constant simplified here as 1

om = 2*pi*new_freq ; %new_freq is an array of values

C1 = exp(-1i*L.*om./c); % L and c are constant

% phi = exp(1i*om*L/c);

syms n

nume = exp(1i.*om.*n*L/c)*4.*n./((1+n).^2); % terms depending on n

denom = 1 + exp(2*1i.*om.*n*L/c).*((n-1)./(n+1)).^2; % terms depending on n

S = arrayfun(@(EQN) vpasolve(EQN,n,guess), M_mag./C1 == nume./denom)

##### 2 Comments Show NoneHide None

Show NoneHide None

Goncalo Costa on 18 Nov 2022

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/1854258-how-do-i-correctly-use-vpasolve#comment_2471373

Dear @Walter Roberson, I have never understood how arrafun works, but it seems to be giving me the right answer. Have you got any link that explain the function written above?

Thank you for your help.

PS: For some reason, the first cell in the cell array separates the complex from the real part of the number.But that can be easily sorted.

Walter Roberson on 18 Nov 2022

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/1854258-how-do-i-correctly-use-vpasolve#comment_2472973

Open in MATLAB Online

result = arrayfun(FUNCTION, ARRAY)

is effectively the same as

if isempty(ARRAY)

result = [];

else

out1 = FUNCTION(ARRAY(1));

result = zeros(size(ARRAY), class(out1));

result(1) = out1;

for K = 2 : numel(ARRAY)

result(K) = FUNCTION(ARRAY(K));

end

end

and

result = arrayfun(FUNCTION, ARRAY, 'uniform', 0)

is effectively the same as

result = cell(size(ARRAY));

for K = 1 : numel(ARRAY)

result{K} = FUNCTION(ARRAY(K));

end

and

result = arrayfun(FUNCTION, ARRAY1, ARRAY2)

is effectively the same as

assert(isequal(size(ARRAY1), size(ARRAY2)), 'input arrays must be the same size');

if isempty(ARRAY1)

result = [];

else

out1 = FUNCTION(ARRAY1(1), ARRAY2(1));

result = zeros(size(ARRAY1), class(out1));

result(1) = out1;

for K = 2 : numel(ARRAY1)

result(K) = FUNCTION(ARRAY1(K), ARRAY2(K));

end

end

So you input a function handle (typically), and one or more arrays that must be exactly the same size. The output is the same size as the array. When 'uniform', 0 is specified, the output is a cell array containing the result of executing the function on each corresponding sets of values from the array in turn. If 'uniform', 0 is not specified, the output is a regular array containing the result of executing the function on each corresponding set of values from the array in turn.
