Hello,

I am attempting to solve a system of nonlinear equations, but unfortunately, vpasolve find answer outside the range I specified and also ignores the constrain condition using "assume".

Here is my code:

% ------------ Parameters --------------------

M = 2;

N = 4;

a = 22.3702/25.4;

beta_10 = 3.41;

k0 = 4.9348;

K2 = 493.2753;

V = [0.7509 1.0000 1.0000 0.7509];

Zb = [-13.0203-6.9290i -19.0747-10.8648i -38.1365-9.9235i -46.2847-14.8522i];

X = [0.1672 -0.2434 0.1502 -0.0871 ; 0.0871 -0.1502 0.2434 -0.1672];

% ------------ Required Functions --------------------

syms g(x) h1(y) h2(y) v(x)

g(x) = 1.177.*sin((pi.*x)./a).^2;

h1(y) = 1-275.*(y-1).^2;

h2(y) = -14.*(y-1);

h(y) = h1(y) + 1i*h2(y);

v(x) = 1.517+1.833.*x.^2;

% ------------ Equation Functions --------------------

x = sym('x',[M N]);

y = sym('y',[M N]);

E1 = []; E2 = []; E3 = []; eq3 = 0; eq4 = 0;

j = 1;

for i = 1:N

Fn = ((cos((beta_10/k0)*y(j,i)*v(x(j,i)))-cos(y(j,i)*v(x(j,i))))/sin(y(j,i)*v(x(j,i))))*(sin(pi*x(j,i))/a);

Ya_G0 = (K2*Fn^2) / (((K2*Fn^2)/(g(x(j,i))*h(y(j,i))))+(Zb(j,i)));

E1 = [E1; imag((K2*Fn^2)/(g(x(j,i))*h(y(j,i)))) == -1*imag(Zb(j,i))];

if i==1 && j==1

Fn_1 = Fn;

Ya_G0_1 = Ya_G0;

else

if mod(i-1,2) == 1

sign = -1;

else

sign = +1;

end

E2 = [E2; (Ya_G0/(Fn)) == (-1)^(j-1)*sign * abs(V(j,i)/V(1,1)) * (sin(y(j,i)*v(x(j,i)))/(sin(y(1,1)*v(x(1,1))))) * (Ya_G0_1/(Fn_1)) ];

end

eq3 = eq3 + Ya_G0;

end

E3 = [E3; eq3 == 2];

E = [E1.',E2.',E3.'];

assume(x,"real"); assumeAlso(x<0.48*a);

assume(y,"positive"); assumeAlso(y,"real");

X_T = X.';

X_trial = X_T(:).';

sol_initial = [X_trial(1:M*N/2),ones(1,M*N/2)];

% sol_range = [all_x_range(1:M*N/2,:);repmat([0.96 1.04],M*N/2,1)];

% sol_initial = sol_range;

x_T = x.'; x_unknown_vector = x_T(:).';

y_T = y.'; y_unknown_vector = y_T(:).';

unknown = [x_unknown_vector(1:M*N/2),y_unknown_vector(1:M*N/2)];

S = vpasolve(E,unknown,sol_initial);

MyFieldNames = fieldnames(S);

MyValuesX = zeros(1,M*N/2); MyValuesY = zeros(1,M*N/2);

for i=1:M*N/2

MyValuesX(1,i) = getfield(S,MyFieldNames{i});

MyValuesY(1,i) = getfield(S,MyFieldNames{i+N/2});

end

round(MyValuesY,3)

ans = 1×4

0.1500 -0.0870 1.0050 1.0070

I also used the range for "vpasolver" as commented "sol_range" in the above code, but I didn't get the desired result either.

The solution to "y" should be a number around 1.

Thanks for your help in advance.

##### 0 Comments Show -2 older commentsHide -2 older comments

Show -2 older commentsHide -2 older comments

Sign in to comment.

Sign in to answer this question.

### Accepted Answer

Moved: Torsten on 4 Feb 2024

vpasolve is a numerical solver - symbolic commands like "assume" are not respected. But you can set ranges for the variables in "vpasolve" by setting "init_param" to a numerical search interval.

##### 6 Comments Show 4 older commentsHide 4 older comments

Show 4 older commentsHide 4 older comments

Faraz j on 4 Feb 2024

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/2078046-assume-can-t-constrain-vpasolve#comment_3053106

Open in MATLAB Online

I defined the range as

all_x_range = repmat([0 a/2;-a/2 0],M*N/2,1);

sol_range = [all_x_range(1:M*N/2,:);repmat([0.96 1.04],M*N/2,1)];

but still give me a solution outside of this range !!!!

Torsten on 4 Feb 2024

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/2078046-assume-can-t-constrain-vpasolve#comment_3053306

Most probably, no solution for y in the specified range can be found.

Faraz j on 5 Feb 2024

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/2078046-assume-can-t-constrain-vpasolve#comment_3053696

Edited: Faraz j on 5 Feb 2024

Open in MATLAB Online

This is the solution vpasolve should find !

MyValuesX = [0.167 -0.2434 0.1502 -0.0871];

MyValuesY = [1.005 1.007 1.0075 1.0114];

Torsten on 5 Feb 2024

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/2078046-assume-can-t-constrain-vpasolve#comment_3053791

Edited: Torsten on 5 Feb 2024

Open in MATLAB Online

Ok, vpasolve failed.

Here is a numerical solution with "lsqnonlin":

% ------------ Parameters --------------------

M = 2;

a = 22.3702/25.4;

beta_10 = 3.41;

k0 = 4.9348;

K2 = 493.2753;

V = [0.7509 1.0000 1.0000 0.7509];

Zb = [-13.0203-6.9290i -19.0747-10.8648i -38.1365-9.9235i -46.2847-14.8522i];

X = [0.1672 -0.2434 0.1502 -0.0871 ; 0.0871 -0.1502 0.2434 -0.1672];

% ------------ Required Functions --------------------

syms g(x) h1(y) h2(y) v(x)

g(x) = 1.177.*sin((pi.*x)./a).^2;

h1(y) = 1-275.*(y-1).^2;

h2(y) = -14.*(y-1);

h(y) = h1(y) + 1i*h2(y);

v(x) = 1.517+1.833.*x.^2;

% ------------ Equation Functions --------------------

x = sym('x',[M N]);

y = sym('y',[M N]);

E1 = []; E2 = []; E3 = []; eq3 = 0; eq4 = 0;

j = 1;

for i = 1:N

Fn = ((cos((beta_10/k0)*y(j,i)*v(x(j,i)))-cos(y(j,i)*v(x(j,i))))/sin(y(j,i)*v(x(j,i))))*(sin(pi*x(j,i))/a);

Ya_G0 = (K2*Fn^2) / (((K2*Fn^2)/(g(x(j,i))*h(y(j,i))))+(Zb(j,i)));

E1 = [E1; imag((K2*Fn^2)/(g(x(j,i))*h(y(j,i)))) - (-1*imag(Zb(j,i)))];

if i==1 && j==1

Fn_1 = Fn;

Ya_G0_1 = Ya_G0;

else

if mod(i-1,2) == 1

sign = -1;

else

sign = +1;

end

tmp=(Ya_G0/(Fn)) -( (-1)^(j-1)*sign * abs(V(j,i)/V(1,1)) * (sin(y(j,i)*v(x(j,i)))/(sin(y(1,1)*v(x(1,1))))) * (Ya_G0_1/(Fn_1)) );

E2 = [E2; tmp ];

end

eq3 = eq3 + Ya_G0;

end

E3 = [E3; eq3 - 2];

E = [E1.',E2.',E3.'];

Enum = matlabFunction(E);

Enum = @(z)real(Enum(z(1),z(2),z(3),z(4),z(5),z(6),z(7),z(8)));

all_x_range = repmat([0 a/2;-a/2 0],M*N/2,1);

sol_range = [all_x_range(1:M*N/2,:);repmat([0.96 1.04],M*N/2,1)];

lb = sol_range(:,1);

ub = sol_range(:,2);

format long

solnum = lsqnonlin(Enum,(lb+ub)/2,lb,ub,optimset('TolX',1e-12,'TolFun',1e-12))

Local minimum possible.lsqnonlin stopped because the final change in the sum of squares relative to its initial value is less than the value of the function tolerance.

solnum = 8×1

0.167210839303176 -0.243345930008853 0.150185145920223 -0.087101777478330 1.005182169079357 1.007061443401629 1.007465052260141 1.011445713909488

Enum(solnum)

ans = 1×8

1.0e-12 * -0.071942451995710 0.156319401867222 0.099475983006414 -0.110134124042816 0 -0.000888178419700 -0.001554312234475 0.000444089209850

Faraz j on 6 Feb 2024

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/2078046-assume-can-t-constrain-vpasolve#comment_3054861

Edited: Faraz j on 6 Feb 2024

Open in MATLAB Online

Thanks a lot ! you're life saver

One more issue @Torsten! for different M and N, how can I modify this

Enum = @(z)real(Enum(z(1),z(2),z(3),z(4),z(5),z(6),z(7),z(8)));

Torsten on 6 Feb 2024

#### Direct link to this comment

https://www.mathworks.com/matlabcentral/answers/2078046-assume-can-t-constrain-vpasolve#comment_3055721

Edited: Torsten on 6 Feb 2024

Open in MATLAB Online

Enum = matlabFunction(E,'Vars',{[x(1,1:N),y(1,1:N)]})

Enum = @(z)real(Enum(z.'));

instead of

Enum = matlabFunction(E);

Enum = @(z)real(Enum(z(1),z(2),z(3),z(4),z(5),z(6),z(7),z(8)));

This is at least correct for the equations you solved above since j was not increased and remained 1 (so I don't know why you created x and y as x(M,N) and y(M,N) and not as x(1,N) and y(1,N))

Sign in to comment.
